MERIDA SCULTURA 4000 2026 - METALLIC BLACK

MERIDA SCULTURA 4000 2026 - METALLIC BLACK

CycleWorx is rated 5.0 on Google 66 reviews
Regular price $2,999.00
Regular price Sale price $2,999.00
Sale Sold out
Shipping calculated at checkout.

Up to 36 months interest-free from $20/wk with Now Rewards Visa^

RIDE READY TODAY.
PAY LATER!

^T&Cs, credit criteria & fees apply. Learn more about fees

👆 Click to apply
Size
Quantity
Out of stock  ·  Papamoa store
Low stock  ·  Only 1 remaining from supplier
View full details

Features

  • Lightweight CF3 carbon frame (approx. 997 g - in size M) with race proven (identical to REACTO) geometry
  • Shimano 105 12-speed groupset
  • MERIDA EXPERT SL II stem
  • MERIDA EXPERT SL handlebar
  • MERIDA EXPERT SL wheelset
  • MERIDA EXPERT CC carbon seat post and DISC COOLER technology

Based around the latest, super smooth 12-speed 105 groupset from Shimano and featuring our award-winning SCULTURA CF3 full carbon frame, the SCULTURA 4000 is far from an entry bike to our latest SCULTURA frame design family. Similarly to its bigger brothers, it combines a long list of air slicing features and race-proven geometry, adapted from our REACTO family, with low weight and class-leading riding comfort creating an almost unbeatable package.

The fifth generation of our lightweight racer marries outstanding handling with improved comfort and an even more aerodynamic chassis. Thanks to incorporating selected aero details from our test and award-winning REACTO aero bike, the SCULTURA is the most aerodynamic version ever. Yet, it remains true to its lightweight, agility and rider comfort focus; in fact it takes these factors to the next level, so far that Cycling Weekly gave it the highly sought after 'Best Value Race Bike of the Year 2024' award. The SCULTURA demonstrates outstanding compliance, providing the rider with class-leading riding comfort that will help to keep the body fresh for the final sprint or ascent. Available in CF5 and CF3 carbon frame versions, both sharing their geometry with the World Tour proven REACTO, our classic road bike combines outstanding comfort with whippet-like acceleration and class-leading climbing pedigree.

Specifications +
Specifications subject to change without prior notice.
FRAME SCULTURA CF3 V, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12mm axle standard, Pressfit 86.5
FORK MERIDA SCULTURA CF3 disc
BRAKES Shimano 105
ROTORS Shimano RT54, 160mm
BRAKE LEVER Shimano 105
HEADSET FSA ACR NO.55R
HANDLEBAR MERIDA EXPERT SL II, material: aluminium, 380mm (3S-XXS-XS-S), 400mm (M-L), 420mm (XL)
HANDLEBAR STEM FSA SMR-II, material: aluminium, -10°, 90 mm (3XS/XXS/XS), 100 mm (S), 110 mm (M/L), 120 mm (XL)
GRIP MERIDA ROAD EXPERT
DERAILLEUR (F) Shimano 105
DERAILLEUR (R) Shimano 105
SHIFTERS Shimano 105 disc
SEAT POST MERIDA EXPERT SL, carbon, 27.2mm diameter, 0mm setback
SEAT CLAMP MERIDA EXPERT
SADDLE MERIDA EXPERT SL
CHAIN Shimano M6100-12
CRANK Shimano 105 R7100, 50-34 teeth, 160 mm-3S, 165 mm-XXS/XS, 170 mm-S/M, 172.5 mm-L/XL
FREEWHEEL Shimano 105 R7101, 11-34 teeth, 12 speed
BOTTOM BRACKET Shimano SM-BB71-41B, Pressfit 86.5
HUBS Shimano TC500 / Shimano TC500-HL, 100x12mm width front hub, 12x142mm width rear hub, 28 spoke hole
RIM MERIDA EXPERT SL, 17mm inner width, 22mm height, material: aluminium
TYRE FRONT Continental Grand Prix, 700x28C, folding
TYRE REAR Continental Grand Prix, 700x28C, folding
AXLES MERIDA EXPERT SL, including removable lever, 6/4mm allen key
SPOKES Double Butted Black stainless
APPROX. WEIGHT 8.5 kg (54cm)
MAX. WEIGHT 120 kg
