MERIDA ONE FORTY 400 2026

MERIDA ONE FORTY 400 2026

Regular price $3,399.00 NZD
Regular price $3,399.00 NZD Sale price $3,399.00 NZD
Taxes included.
Size
Colour
Quantity

❌ Out of Stock at Papamoa

✅ In Stock at Warehouse

Features

  • Full aluminium frame with FAST kinematic suspension and AGILOMETER sizing
  • Radical trail geometry with full 29er wheels
  • Marzocchi suspension, 150 mm front, 143 mm rear
  • Durable, wide-range Shimano CUES 11-speed drivetrain
  • 230 mm dropper post on XLong, 200 mm on Long, 170 mm on Mid and 150 mm on Short and XShort
  • Powerful 4-piston SRAM DB4 hydraulic disc brakes

The ONE-FORTY 400 brings an unheard of level of climbing and descending performance into a high-value package built around our test and award-winning aluminium frame. It's got exactly the same ground-breaking geometry as its more expensive brethren, just paired with kit that delivers the performance you need, without the price tag. Dropper posts on all models, a wide-range 11-speed Shimano drivetrain and no-nonsense suspension from Marzocchi get the job done without fuss.

The test and award-winning ONE-FORTY is the ultimate trail bike, made for the toughest trails in the world. It’s the pinnacle of modern trail riding, with a super-steep 80° seat angle, low front end and bottom bracket allow it to clear the most technical climbs, while longer reach figures across all sizes and a well-balanced 65° head angle mean it’s still more than capable of ripping any descent. With our AGILOMETER sizing system, riders can run a longer or shorter reach frame independently of their height, with suspension that becomes more progressive as you size up to better cope with heavier/harder riders. We’ve focused on weight reduction and rolling speed too, for improved efficiency. All bikes come with long travel dropper posts, WIRE PORT cable routing and a reliable threaded bottom bracket plus carbon frames have on-board tool storage and Fidlock magnetic bottle cages.

Specifications
Please note - specifications subject to change without prior notice.
FRAME ONE-FORTY LITE III, 143 STR 29", MAT aluminium, 29x2.5" max. WHS, 148x12 AST, BSA BBR,
SHOCK Marzocchi Bomber inline,
FORK Marzocchi Z2, Air, 150 STR, Tapered, 44mm fork offset, 29x2.6" max. WHS,
BRAKE FRONT Sram DB4, 4 piston
BRAKE REAR Sram DB4, 4 piston
ROTOR FRONT Sram CenterLine, 200mm
ROTOR REAR Sram CenterLine, 200mm
CHAIN KMC xGlide,
CRANKSET MERIDA Expert TR II, 32t
CRANK LENGTH 170 mm for all sizes,
BB SET Samox BSA 24mm EB2401,
DERAILLEUR FRONT 0,
DERAILLEUR REAR Shimano CUES U6000, Shadow Plus
CASSETTE SunRace 10-50t CS-UX400 EA5, 10-50t, 11sp Linkglide
PEDAL 0,
GRIP MERIDA COMP TR,
HANDLEBAR MERIDA COMP TR, MAT aluminium, 780 WHB, 20 RHB
STEM MERIDA COMP TR, MAT aluminium, 35 DSH, 0 ASD
STEM SIZE 40 mm,
HEADSET Acros ICR MERIDA EXTERNAL neck, Upper and lower IPS sealing
HUB FRONT Shimano TC500-B, 110x15 WHF, 32 SPH, Centerlock
HUB REAR Shimano TC500-HM-B, 148x12 WHR, 32 SPH, Centerlock
RIM MERIDA COMP TR II, 110x15 WHF, 148x12 WHR, 28 IWR, MAT aluminium, Tubeless ready (tubeless tape and valves not included), 29",
SADDLE MERIDA COMP SL, 25% recycled material, V-mount, incl. MERIDA minitool
SEAT CLAMP MERIDA EXPERT,
SEAT POST MERIDA EXPERT TR II, 34.9 DSP, 0 SSB, XSHORT/SHORT: 150mm travel - MID: 170mm travel - LONG: 200mm travel - XLONG: 230mm travel
SHIFTER FRONT 0,
SHIFTER REAR Shimano CUES U6000,
TYRE FRONT Maxxis Minion DHF, 29x2.5", wire,
TYRE REAR Maxxis Forekaster, 29x2.4", wire,
